Model | MP3320 | |
Inputs | 3 x XLR (Balanced/Unbalanced) Mic/Line, 2 x Aux L+R RCA, 3.5mm Jack to Media Player | |
Audio Source | Internal Bluetooth, USB, FM&AUX Player | |
Outputs | L+R XLR, Mono 6.3mm Jack, Record Out (RCA) | |
Emergency Control | 24V Contacts Mute All Except Channel 1 | |
Phantom Power | +20V (Switchable Channels 1-3) | |
Input Impedance | 2.2k Ohms(Mic/Line),10k Ohms(Aux) | |
Controls | Media,3 xMic/Line,2 xAux,Treble,Bass, Master Level | |
Rear Panel Control | Priority Muting Level, Mic/Line and Phantom DIP Switches | |
Frequency Response | Mic | 20Hz-18kHz |
Line | 14Hz-20kHz | |
Aux | 10Hz-23kHz | |
Input Sensitivity | Mic | -45dBV |
Aux/Line | -10dBV | |
SNR | Mic | 55dB |
Aux/Line | 60dB | |
THD | 0.05% | |
Power Supply | AC110V, 60Hz | |
Fuse | T1AL | |
Dimensions | 482×130×44mm | |
Weight | 1.43kg | |
