Model | DP-W400GF |
Pixel Pitch | 4mm |
Pixel Density | 62500 dots/㎡ |
Module Resolution | 80×64 pixels (W×H) |
Module Dimensions | 320×160×17mm (W×H×D) |
Module Weight | Approximately 450g |
Driving Method | 16-bit constant current |
Scan Mode | 1/10 |
Operating Voltage | DC5V±10% |
Maximum Current | 9A (typical) ① |
Maximum Power Consumption | 45W (typical) ② |
Power Interface | VH4 |
Signal Interface | HUB75 (IDC16) |
Maximum Brightness | ≥6000cd/㎡ |
Color Temperature | 9000±500K |
Viewing Angle | ≤140° |
Optimal Viewing Distance | ≥4m |
Gray Scale | 14-bit |
Brightness & Color Calibration | Support |
Refresh Rate | ≥3000Hz③ |
Load Range | 128×256 pixels (W×H, MAX.) |
Brightness Adjustment Range | 0-255 (adjustable) |
Typical Lifespan | 100,000 hours |
Operating Temperature | -20℃~60℃ |
Operating Humidity | 10%-90%RH, non-condensing |
Storage Temperature | -40℃~80℃ |
