Model | CM21B | |
Input | Mic / Line Input: 1-16 | Balanced, XLR and 1/4" TRS Connectors |
Input Sensitivity (XLR / TRS) | XLR 1.5 mV, TRS 7 mV | |
Input Analog Gain | -32 dB to +10 dB, 0.6–0.7 dB Step | |
Max. Input Level (XLR / TRS) | +19 dBu / +29 dBu | |
Input Impedance (XLR / TRS) | MIC > 5 kΩ, LINE > 10 kΩ | |
Output | Mix 1–8 AUX Outputs | Balanced XLR |
Output Impedance | < 75 Ω | |
Nominal Output Level | +4 dBu = 0 dB Meter Reading | |
Residual Output Noise | -91 dBu | |
Dynamic Noise | 112dB | |
SNR | XLR ≥ 92dB,TRS ≥82dB | |
Max. Output Voltage | 7VAC Max | |
Distortion | ＜0.0003% (1KhzFull Power) | |
Frequency Response | 20HZ -20KHZ+/ -0.5dB | |
